EPCOS / TDK T850 NTC Thermistors

EPCOS / TDK T850 NTC Thermistors are designed for surface temperature measurement and offer 10kΩ rated resistance with 1% or 2% tolerance. These sensors combine high humidity resistance with fast response time and offer a high dielectric strength of 2500VAC for 60s. The modules are suitable for harsh environments in temperatures ranging from -40°C to +150°C and are waterproof for up to 500 hours. The miniature package has an aluminum oxide ceramic surface and dimensions of 10mm x 3mm x 3mm. Additional features include a wider sensing surface area, phosphor bronze electrodes, and mechanical robustness. EPCOS / TDK T850 NTC Thermistors can be attached to a metal heatsink or bars as well as directly to a chassis.

Features

  • Lead free and halogen free
  • Miniature size
  • NTC chip is fully sealed with epoxy
  • High humidity resistance
  • High degree of electrical insulation between measurement surface and NTC provided by Al2O3 ceramic
  • Wider sensing surface area
  • Phosphor bronze electrodes
  • Design is process automation friendly
  • Attachable to metal heatsink or bars and directly to chassis
  • Good mechanical robustness
  • Designed for surface temperature measurement

Applications

  • Heating and building services engineering
  • Heat sinks of power modules
  • Temperature monitoring of industrial processes

Specifications

  • 2500VAC dielectric strength for 60s
  • 10kΩ rated resistance
  • 1% or 2% resistance tolerance
  • 10mm x 3mm x 3mm dimensions (L x W x H)
  • -40°C to +150°C temperature range
  • Waterproof for up to 500hr

Dimensions (mm)

EPCOS / TDK T850 NTC Thermistors
