Renesas Electronics Enterprise Server
Renesas Electronics Enterprise Server is a broad portfolio of power products to address the needs of modern enterprise server systems. Modern servers are placing increasingly difficult demands on power and timing solutions with demanding power and performance requirements. The combination of high performance and specialized timing address these needs.
Features
- Jitter margin offers lower bit error rates and future-proof designs to meet PCIe Gen4 and PCIe Gen5
- Jitter margin allows longer traces before approaching jitter limits, which eases board routing
- Available integrated terminations save up to 130mm2 of area
- Patented low-power HCSL output structures cut power consumption by up to 50%
Block Diagram
Controllers
Memory Interface
Featured Products
Renesas Electronics ISL68201 Buck Controller
Extremely fast transient performance and accurately regulated frequency control.
Renesas Electronics ISL85003/ISL85003A Synchronous Buck Regulators
Integrated high-side and low-side FETs with an input voltage range of 4.5V to 18V.
Renesas Electronics 9ZXL1231E & 9ZXL1251E Clock Buffers
12-output DB1200ZL derivative for PCIe Gen1-4 and UPI with pin-compatible upgrades.
Renesas Electronics 9ZX21901D Clock Buffers
19-output DB1900Z differential buffer for PCIe Gen1-4 and QPI/UPI.
ADDITIONAL APPLICATION SOLUTIONS
See how Renesas' complementary Analog + Power + Embedded Processing product portfolios work together to deliver comprehensive solutions.
Published: 2019-08-27
| Updated: 2023-08-03
