The dual ADC output data is routed directly to the external 14-bit LVDS output port that supports double data rate (DDR) formatting. The SYNC± input pins support multiple device synchronization. In addition, the AD9684 offers flexible power-down options for significant power savings. Designers can program all of the AD9684 features using a 1.8V to 3.4V capable 3-wire serial port interface (SPI). Specified to operate over the −40°C to +85°C industrial temperature range, AD9684 ADCs are well-suited for communications, diversity multiband, multimode digital receivers, 3G/4G, TD-SCDMA, W-CDMA, MC-GSM, LTE, general-purpose software radios, ultrawideband satellite receiver, instrumentation (spectrum analyzers, network analyzers, integrated RF test solutions), radar, digital oscilloscopes, high-speed data acquisition systems, DOCSIS CMTS upstream receiver paths, and HFC digital reverse path receivers.
