Amphenol LTW Waterproof USB 3.0 A Type Connectors

Amphenol LTW Waterproof USB 3.0 A Type Connectors provide USB 3.0 standard data transfer rates (up to 5Gbps) and feature a standard cable length of 1M-3M. Amphenol USB 3.0 A Type Connectors have a 1.5A current rating and an IP67/IP68 waterproof rating. The connectors have a temperature range of up -40°C to up +85°C.

Features

Up to 5Gbps transfer speeds
Temperature range
- Receptacle
  - Nylon+GF and M-PPE: -40°C to +105°C
  - ABS: -20°C to +80°C
- Receptacle with cable
  - Nylon+GF: -20°C to +105°C
  - ABS: -20°C to +80°C
- Overmolded with cable, and field installable: -20°C to +80°C

1.5A current rating
IP67 and IP68 waterproof ratings
≤30mΩ contact resistance
≥1000mΩ at 500V_DC insulation resistance
≥AC500V / 1 minute breakdown voltage
01m to 05m standard cable length
Material
- Copper alloy, gold-plated contacts
- PBT UL 94V-0 connector body (housing)
