Amphenol FCI Minitek® Connectors
Amphenol FCI Minitek® Connectors consist of modular board-to-board connectors suitable for parallel, perpendicular, and coplanar applications. These signal connectors are available in 0.8mm, 1.0mm, 1.27mm, 1.50mm, and 2.0mm pitches. The stackable unshrouded and shrouded headers have through-mount, surface-mount, and pin-in-paste versions. Amphenol FCI Minitek Connectors are customizable in terms of stack heights and the number of available positions.
Features
- Compact and modular
- Customizable in terms of stack heights and number of positions
- Includes hybrid and high-current versions
Applications
- Datacom
- Industrial
- Automotive
- Consumer
- Military
Featured Connectors
Amphenol FCI Minitek MicroSpace™ Connector System
Features a compact, robust, and versatile connector system with top- or side-latch configurations.
Amphenol FCI Minitek® MicroSpeed 1mm Board-to-Board Connectors
1.00mm pitch connectors that support high-speed applications with performance up to 25GB/s.
Amphenol FCI Minitek® Board-In 2.0 & 2.5 Connectors
Offers a 2A to 3A current range, 250VAC/DC rated voltage, and -40°C to +105°C temperature range.
Amphenol FCI Minitek® 2.00mm Blind Mate Interface Connectors
Allows misalignment, provides floating for easy blind-mate connections, 2A current per circuit.
Amphenol FCI Minitek® 1.50mm Single Row Connector System
Secure and space saving solution for devices that carry more signal lines in less space.
Amphenol FCI Minitek127® 1.27mm Board-to-Board Connectors
The Minitek® System includes board-to-board & cable-to-board connectors.
Amphenol FCI Minitek® 1mm Wire-to-Board Connector System
Provides an ideal solution for devices that require compact, low-profile connectors, 1mm pitch.
Amphenol FCI Minitek® 0.8mm Wire-to-Board Connector System
Designed for the finest pitch wire-to-board applications, saves space with the 0.80mm pitch.
Amphenol Communications Solutions Minitek® Pwr Connector System
Cost-effective connectors engineered for wire-to-wire and wire-to-board applications.
Amphenol FCI Minitek® Pwr 3.0 BMI Connector System
5A current rating per contact and available in 8, 12, and 14 circuits for dual-row designs.
Amphenol FCI Minitek® Multipitch 1.25mm Wire-to-Board Connector
Offered in single and double rows with active latching as well as optional TPA and CPA.
Amphenol FCI Minitek® Multipitch 1.5mm Wire-to-Board Connectors
Single row, 2 to 15 position connectors with horizontal configurations, TPA, and CPA.
