TPD4S214YFFR

Name: Texas Instruments TPD4S214YFFR
Brand: Texas Instruments
SKU: 595-TPD4S214YFFR
Price: 0.95 USD
Availability: InStock

Images are for reference only
See Product Specifications

Mouser #:

595-TPD4S214YFFR

Mfr. #:

TPD4S214YFFR

Mfr.:

Texas Instruments

Description:

ESD Suppressors / TVS Diodes USB OTG Companion Device

Datasheet:

TPD4S214YFFR Datasheet

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about ECAD Model.

Add To Project

Add Notes

In Stock: 6

Stock:: 6

Can Ship Immediately

Shipping Restricted
On Order:: 3,000

Expected 18-Apr-23

6,000

Expected 21-Apr-23
Factory Lead-Time:: 42

Weeks Estimated factory production time for quantities greater than shown.

Long lead time reported on this product.

Minimum: 1 Multiples: 1

Enter Quantity:

Unit Price:

$-.--

Ext. Price:

$-.--

Packaging:

Full Reel (Order in multiples of 3000)

Cut Tape

MouseReel™ (+$7.00)

Pricing (USD)

Qty.	Unit Price	Ext. Price
Cut Tape / MouseReel™ ^†
	$0.95	$0.95
	$0.849	$8.49
	$0.662	$66.20
	$0.649	$162.25
	$0.536	$268.00
	$0.428	$428.00
Full Reel (Order in multiples of 3000)
	$0.425	$1,275.00

† $7.00 MouseReel™ fee will be added and calculated in your shopping cart. All MouseReel™ orders are non-cancellable and non-returnable. ↩

Specifications

Products found:

To show similar products, select at least one checkbox

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Texas Instruments
Product Category:	ESD Suppressors / TVS Diodes
RoHS:	Details
Product Type:	ESD Suppressors
Polarity:	Unidirectional
Working Voltage:	5 V
Number of Channels:	4 Channel
Termination Style:	SMD/SMT
Package / Case:	DSBGA-12
Breakdown Voltage:	6 V
Clamping Voltage:	9 V
Pppm - Peak Pulse Power Dissipation:	84 W
Vesd - Voltage ESD Contact:	15 kV
Vesd - Voltage ESD Air Gap:	15 kV
Cd - Diode Capacitance:	1.9 pF
Minimum Operating Temperature:	- 40 C
Maximum Operating Temperature:	+ 85 C
Series:	TPD4S214
Packaging:	Reel
Packaging:	Cut Tape
Packaging:	MouseReel
Brand:	Texas Instruments
Current Rating:	1 uA
Operating Supply Voltage:	30 V
Factory Pack Quantity:	3000
Subcategory:	TVS Diodes / ESD Suppression Diodes
Vf - Forward Voltage:	0.95 V
Unit Weight:	0.000095 oz

Products found:

To show similar products, select at least one checkbox

Select at least one checkbox above to show similar products in this category.

Attributes selected: 0

Documents (8)

Filter Document:

Datasheet

TPD4S214YFFR Datasheet

Images

This functionality requires JavaScript to be enabled.

Product Compliance

USHTS:: 8542390001
CNHTS:: 8536300000
CAHTS:: 8542390000
JPHTS:: 8542390990
MXHTS:: 8542330201
ECCN:: EAR99
