LM2678T-5.0/NOPB

Name: Texas Instruments LM2678T-5.0/NOPB
Brand: Texas Instruments
SKU: 926-LM2678T-5.0/NOPB
Price: 6.31 USD
Availability: InStock

Images are for reference only
See Product Specifications

Mouser #:

926-LM2678T-5.0/NOPB

Mfr. #:

LM2678T-5.0/NOPB

Description:

Switching Voltage Regulators HIGH EFF 5A STEP- DOWN VLTG REG

Datasheet:

LM2678T-5.0/NOPB Datasheet

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about ECAD Model.

Add To Project

Add Notes

In Stock: 502

Stock:: 502 Can Ship Immediately

Shipping Restricted
Factory Lead-Time:: 6 Weeks Estimated factory production time for quantities greater than shown.

Minimum: 1 Multiples: 1

Enter Quantity:

Unit Price:

$-.--

Ext. Price:

$-.--

Pricing (USD)

Qty.	Unit Price	Ext. Price
	$6.31	$6.31
	$5.36	$53.60
	$4.40	$396.00
	$4.22	$1,139.40
	$3.33	$1,798.20
	$3.16	$3,412.80
10,260	Quote

Specifications

Products found:

To show similar products, select at least one checkbox

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Texas Instruments
Product Category:	Switching Voltage Regulators
RoHS:	Details
Mounting Style:	Through Hole
Package / Case:	TO-220-7
Topology:	Buck
Output Voltage:	5 V
Output Current:	5 A
Number of Outputs:	1 Output
Input Voltage, Min:	8 V
Input Voltage, Max:	40 V
Quiescent Current:	4.2 mA
Switching Frequency:	260 kHz
Minimum Operating Temperature:	- 40 C
Maximum Operating Temperature:	+ 125 C
Series:	LM2678
Packaging:	Tube
Brand:	Texas Instruments
Input Voltage:	8 V to 40 V
Operating Supply Current:	4.2 mA
Product Type:	Switching Voltage Regulators
Shutdown:	Shutdown
Factory Pack Quantity:	45
Subcategory:	PMIC - Power Management ICs
Supply Voltage - Min:	8 V
Tradename:	SIMPLE SWITCHER
Type:	Step Down Voltage Regulator
Unit Weight:	0.063493 oz

Products found:

To show similar products, select at least one checkbox

Select at least one checkbox above to show similar products in this category.

Attributes selected: 0

Documents (9)

Filter Document:

Datasheet

LM2678T-5.0/NOPB Datasheet

Images

This functionality requires JavaScript to be enabled.

Product Compliance

USHTS:: 8542390001
CNHTS:: 8542399000
CAHTS:: 8542390090
JPHTS:: 854239099
TARIC:: 8542399000
MXHTS:: 8542399901
ECCN:: EAR99
