LM2675N-5.0/NOPB

Name: Texas Instruments LM2675N-5.0/NOPB
Brand: Texas Instruments
SKU: 926-LM2675N-5.0/NOPB
Price: 5.51 USD
Availability: InStock

Images are for reference only
See Product Specifications

Mouser #:

926-LM2675N-5.0/NOPB

Mfr. #:

LM2675N-5.0/NOPB

Description:

Switching Voltage Regulators HIGH EFF 1A STEP- DOWN VLTG REG

Datasheet:

LM2675N-5.0/NOPB Datasheet

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about ECAD Model.

Add To Project

Add Notes

In Stock: 50

Stock:: 50

Can Ship Immediately

Shipping Restricted
On Order:: 1,000

Expected 05-Feb-24

1,680

Expected 11-Sep-24
Factory Lead-Time:: 48

Weeks Estimated factory production time for quantities greater than shown.

Minimum: 1 Multiples: 1

Enter Quantity:

Unit Price:

$-.--

Ext. Price:

$-.--

Pricing (USD)

Qty.	Unit Price	Ext. Price
	$5.51	$5.51
	$4.96	$49.60
	$4.06	$487.20
	$3.85	$1,078.00
	$3.46	$1,799.20

Specifications

Products found:

To show similar products, select at least one checkbox

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Texas Instruments
Product Category:	Switching Voltage Regulators
RoHS:	Details
Mounting Style:	Through Hole
Package / Case:	PDIP-8
Topology:	Buck
Output Voltage:	5 V
Output Current:	1 A
Number of Outputs:	1 Output
Input Voltage, Min:	8 V
Input Voltage, Max:	40 V
Quiescent Current:	2.5 mA
Switching Frequency:	260 kHz
Minimum Operating Temperature:	- 40 C
Maximum Operating Temperature:	+ 125 C
Series:	LM2675
Packaging:	Tube
Brand:	Texas Instruments
Development Kit:	LM2675-5.0EVAL
Input Voltage:	8 V to 40 V
Operating Supply Current:	2.5 mA
Product Type:	Switching Voltage Regulators
Shutdown:	Shutdown
Factory Pack Quantity:	40
Subcategory:	PMIC - Power Management ICs
Supply Voltage - Min:	8 V
Tradename:	SIMPLE SWITCHER
Type:	Step Down Voltage Regulator
Unit Weight:	0.015521 oz

Products found:

To show similar products, select at least one checkbox

Select at least one checkbox above to show similar products in this category.

Attributes selected: 0

Documents (13)

Filter Document:

Datasheet

LM2675N-5.0/NOPB Datasheet

Images

Models

LM2675N-5.0/NOPB Symbol & Footprint by SnapEDA

PCN

SPICE Models

Technical Resources

Show All

Show Less

Environmental Documents

This functionality requires JavaScript to be enabled.

Product Compliance

USHTS:: 8542390001
CNHTS:: 8542399000
CAHTS:: 8542390090
JPHTS:: 854239099
TARIC:: 8542399000
MXHTS:: 8542399901
ECCN:: EAR99
